Electrical Wire Spot Welding Machine 4feet 5feet For Animal Cage
| Place of Origin | HEBEI, CHINA |
|---|---|
| Brand Name | DIAOZHUO |
| Certification | CE ISO9001 |
| Model Number | DZ1200 DZ1500 Z2000 DZ2500 |
| Minimum Order Quantity | 1set |
| Price | variable |
| Packaging Details | woodencase and plastic bags |
| Delivery Time | 20-30 days |
| Payment Terms | L/C, D/P, T/T |
| Supply Ability | 30 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Control | PLC Fully Automatic | Finial Products | In Rolls |
|---|---|---|---|
| Width | 1200mm 1500mm 2000mm | Material | Gal Wire, Iron Wire, Black Wire |
| Engineer | Can Help Of The Installation Work | Shipment | Containers |
| High Light | 4feet Wire Spot Welding Machine,5feet Wire Spot Welding Machine,4feet Wire Cage Welding Machine |
||
Product Description
electrical welded wire mesh machine, spot welded mesh machine
Welded wire mesh machine, also called, welded roll mesh machine, electric welded mesh machine. Our roll welding wire mesh machine is featured by wire coil feeding and invert speed control.It is used to make wall mesh,construction mesh,animal cage, mining etc.
machine details:
| Model | DZ-DNW-1 | DZ-DNW-2 | DZ-DNW-3 |
| Wire diameter | 0.4-0.65mm | 0.65-1.2/1.8mm | 1.0-2.2mm/2.5mm |
| Aperture/pitch | 1/4”-1/2” | 1/2”-4” | 1”-4” |
| Mesh width | 3 feet, 4feet | 4 feet, 5 feet | 4 feet, 5 feet, 6 feet, 7feet |
| Motor | 2.2kw | 2.2kw | 2.2kw;4.0kw |
| Welding speed | Max.75 rows/min | Max.120 rows/min | Max.80 rows/min |
| Measurement | 2.3*1.3*1.4m | 2.5/2.9*1.3*1.4m | 2.5/2.9*1.3*1.4m |
| Weight | 1.5T | 2T, 2.5T | 2T, 2.5T, 3T, 3.5T |
| Transformers | 50kva*3 | 60kva*4;60kva*5 | 60kva*4/5/6/7 |
1. This kind of wire mesh welding machine is our latest developed reinforcing mesh welding machine.
2. The line wire and the weft wire of wire mesh welding machine are pre-straight and pre-cut.
3. The line wire is feeding by the servo motor ,pulling the wire net by the servo motor auto.
4. The wire mesh welding machine welding power comes from the cylinders. It’s easy to control the welding pressure .
5. The weft wire of wire mesh welding machine feeding from the multi hopper which capacity is more over ten times than the traditional hopper.
6. The new wire mesh welding machine added the bear wire net and carry equipment that makes the working more convenience .
7. The welding part of wire mesh welding machine is used the springiness input wire trunking that makes the welding copper use for long time.
8. This wire mesh welding machine adopts synchronous control technique. The cent-control and welding time are composed of PLC program system. The input front-panel is touch screen , the operate is more intelligent and reasonable.
what u would like to know?
Q: What's the machine price?
A: We need to know your wanted wire diameter, mesh hole size and mesh width.
Q: What's the production capacity?
A: The production capacity mainly depends on the welding speed and cross wire space.
Q: Can you make voltage according to my requirement?
A: yes, we can make 3 phase, 380V/220V/415V/440V, 50Hz or 60Hz etc.
Q: What's the payment terms?
A: 30% T/T in advance, 70% T/T before shipment, or 100% irrevocable L/C at sight, or cash etc. It is negotiationable.
