8mm Automatic Mesh Welding Machine 60times/min Wire Cage Welding Machine

Place of Origin CHINA
Brand Name DIAOZHUO
Certification CE ISO9001
Model Number DZ1000 DZ1200 DZ2000 DZ2500 DZ3000
Minimum Order Quantity 1SET
Price variable
Packaging Details NUDE
Delivery Time 20-30 DAYS
Payment Terms L/C, T/T, D/P
Supply Ability 30 SETS ONE MONTH

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
WIRE From 2mm To 8mm Can Be Made By Required TYPE Automatic Welding Machine
ENGINEER Door To Door Services PRODUCT NAME Welding Fence Machine
DELIVERY TIME 20 DAYS CROSS WIRE Fully Automatic Falling
Highlight

8mm Automatic Mesh Welding Machine

,

ISO9001 Automatic Mesh Welding Machine

,

Wire Cage Welding Machine Wire Cage Welding Machine

Leave a Message
Product Description

wire cage welding mesh machine, animals cage mesh welding machine



Full automatic wire mesh welding machine adopts mechanical eccentric wheel pressure, servo motor and precision reducer back and forth to pull mesh movement, so as to realize the perfect combination of mechanical motion and servo CNC system. Mesh size is easy and convenient to adjustis, maintenance is simple and operation cost is low. Longitudinal wire feeding adopts large disc feeder, system automatic detection, automatic feeding line wire, The cross wire is pre-cut automatic feeding by stepping motor controlled. So as to ensure that part of the servo dragnet pull even, The cross wire hopper can storage more cross wires, not easy to mess.The wire mesh welding machine is highly automated, saves labor and greatly improves production efficiency.



1. This machine can make both of panel mesh and roll mesh

2. Line wires are fed from wire coils automatically and through straightening rollers

3. Cross wire should be pre-cut and fed by cross wire feeder automatically

4. Equipped with cutting machine to make panel mesh and rolling machine to make roll mesh

5. Welding electrodes- chromium zirconium copper Upper-20mm diameter Lower-20*20*20mm, can be used 6 sides, The welding electrode distance can be adjusted.

6. Main motor (11kw) planetary reducer connect the main axis directly, instead of by chain. It is not easily broken. High stability. Big transmission torque, suitable for high welding speed.

7. Cast water cooling welding transformers Suitable for high temperature. When 2.5-4mm one welding transformer controls 8 welding electrodes. When 4-6mm, one welding transformer controls 4 welding electrodes.

8. Panasonic brand servo motor (2kw) for mesh pulling, accurate, big power. SMC air cylinders controls the hook up and down.

JT brand pulling rack, less noise, high accuracy.

9. The mesh cutting machine set the cut mesh length in the control cabinet. Will cut the mesh automatically when the mesh size up to the set mesh length. After cutting the mesh panel. The falling mesh device will drop the mesh panel automatically.

10. The roll mesh length max up to 60m per roll. And the roll mesh machine is variable-frequency. The roll mesh speed is adjusyable.

11. The Wire Mesh Welding Machine adopts line wire straighten system. special design structure ensure the straighteness of the line wires from 2 directions. The straightening wheels are made of alloy steel with long lifetime. It can straighten different materials. Such as: galvanized wire, cold-rolled ribbed wire, low carbon black wire.

12. The Wire Mesh Welding Machine adopts cross wire feeding with hopper with large storage.reduce the labor to input the wire material frequently.Wire blanking smoothly with the inspection device will alarm and machine stop working automatic if the cross wire is dropping improperly or cross wire disordered.



Main parameters



Wire diameter 2.5~6mm Line wire form pre-cut wire
Weft wire distance 25--300mm Weft wire form pre-cut wire
Line wire distance 50~300mm Rated voltage 380V 50Hz
Welding net width 2500mm Rated power 6*125KVA
Welding speed 45--60times/min Overall dimention 8*3.2*1.7m
Line wire No. 51 Wire net length 6000mm



some other informations about myafter-seales service:



The general manufacturers only provide the services of basic production machines. Even after the handover of the machines, the business is completed. For us, the delivery of safe, high-quality machines to customers is only the beginning of our services.



A: before send every machine we will test in the best working situation and take pics, visdeos to every client to help every client to know what they will got

B: during the production time, we will report the working situation every week by pics and videos. to hlep the clients to know what we are doing for them

C: we will invit every client to visit my factory and check their machine together to hep them make clear who and how does the factory he is doing business with

D:we will arrange our engineer to install the machines in CLIENT'S factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.

Full automatic wire mesh welding machine adopts mechanical eccentric wheel pressure, servo motor and precision reducer back and forth to pull mesh movement, so as to realize the perfect combination of mechanical motion and servo CNC system. Mesh size is easy and convenient to adjustis, maintenance is simple and operation cost is low. Longitudinal wire feeding adopts large disc feeder, system automatic detection, automatic feeding line wire, The cross wire is pre-cut automatic feeding by stepping motor controlled. So as to ensure that part of the servo dragnet pull even, The cross wire hopper can storage more cross wires, not easy to mess.The wire mesh welding machine is highly automated, saves labor and greatly improves production efficiency.
